Features

• Versatile 4-way convertible design for upflow, downflow, horizontal left and horizontal right applications.
• Factory-installed indoor coil.
• Sturdy cabinet construction with 1.0 inch [25.4 mm] of foil faced insulation for excellent sound and insulating characteristics.
• Field-installed auxiliary electric heater kits provide exact heat for indoor comfort. Kits include circuit breakers which meet U.L. and cUL requirements for service disconnect.
• 11/2 ton [5.3 kW] through 5 ton [17.6 kW] models are between 421/2 to 551/2 inches [1080 to 1410 mm] tall and 22 inches [559 mm] deep.
• All models meet or exceed 330 to 400 CFM [156 to 189 L/s] per ton at .3 inches [.7 kPa] of external static pressure.
• Enhanced airflow up to .7" external static pressure.
• Evaporator is constructed of aluminum fins bonded to internally grooved aluminum tubing.

Specifications

• Efficiencies up to 15 SEER
• Versatile 4-way convertible design for upflow, downflow, horizontal left and horizontal right applications.
• Factory-installed indoor coil.
• PSC Single Stage Airflow
• Aluminum coil
• Thermostatic Expansion Valve (TXV)
